Wilden PS1 Pump 13 mm (1/2″) Pro-Flo® SHIFT Saniflo™ FDA Series Clamped Metal AODD
PS1
Pump Size
1/2”
Air inlet
1/2” FNPT
Liquid Inlet
1”
Liquid discharge
1”
Connection type
Tri-Clamp
Max suction lift Capacity
Rubber – 5.9 m Dry (19.3’), 9.8 m Wet (32.3’)
TPE – 5.7 m Dry (18.7’), 8.3 m Wet (27.2’)
PTFE – 4.3 m Dry (14.2’), 9.7 m Wet (31.7’)
Max flow rate
Rubber – 60.2 lpm (15.9 gpm)
TPE – 60.2 lpm (15.9 gpm)
PTFE – 59.8 lpm (15.8 gpm
Max pressure
8.6 bar pressure (125 psi)
Max diameter solids
1.6mm
Displacement per stroke
Rubber – 0.10 L (0.026 gal)
TPE – 0.10 L (0.026 gal)
PTFE – 0.10 L (0.026 gal)
Pump Details
The Wilden Saniflo FDA series pumps cater to standard food processing needs that don’t necessitate the hygienic series (HS) or clean-in-place (CIP) features. Ideal for the sanitary environments handling high acid, high sugar and high fat substances, these pumps offer straightforward installation and a sturdy build. Compliant with FDA, CE,EC 1935/2004 and ATEX standards, they ensure reliability and regulatory adherence
- Tri-clamp connections with wingnut clamped design
- Quick breakdown/reassembly for cleaning
- Greater flow – more gallons pumped per SCFM
- Two air distribution system options:
- Pro-Flo® SHIFT: multiple material options, high efficiency, high flow
- Pro-Flo: durable, economical, one material option
