Wilden PS1500 Pump 76 mm (3″) Pro-Flo® SHIFT Series Bolted Plastic AODD
PS1500
Pump Size
3”
Air inlet
3/4” FNPT
Liquid Inlet
3”
Liquid discharge
3”
Connection type
DIN/ANSI (Flanged)
Max suction lift capacity
EZ-Install TPE – 5.3 m (17.5′) Dry, 8.3 m (28.4′) Wet, Full-Stroke PTFE – 5.8 m (19.1′) Dry, 8.6 m (28.4′) Wet, Reduced-Stroke PTFE – 3.5 m (11.6′) Dry, 8.6 m (28.4′) Wet
Max flow rate
EZ-Install TPE – 1,024 lpm (271 gpm), Full-Stroke PTFE – 999 lpm (262 gpm), Reduced-Stroke PTFE – 882 lpm (233 gpm)
Max pressure
Polypropylene – 6.9 bar (100 psi), PVDF – 8.6 bar (125 psi)
Max diameter solids
13mm
Displacement per stroke
EZ-Install TPE – 5.4 L (1.42 gal), Full-Stroke PTFE – 5.3 L (1.40 gal), Reduced-Stroke PTFE – 3.5 L (0.93 gal)
Pump Details
The Wilden Pro-flo Shift (PS) is the industry premier air distribution system (ADS) and your ideal solution to increase productivity, lower energy consumption, reduce air consumption and simplicity in maintenance. The design benefits are unmatched by any other ADS on the market. Wildens Pro-flo shift features an air control spool that automatically optimises air consumption and eliminates overfilling of the air chamber with no reduction in flow rate.
Features and benefits of the Pro-Flo SHIFT ADS include:
- Up to 60% in air savings all while retaining existing flow rates
- Reduced total cost of ownership
- Ease of maintenance
- Ability to be used in harsh operating environments
- No electricity required
- Designed off the same basic design principles as the tried and true Pro-Flo Series Unbalanced spool preventing stalling.
- Simple pilot spool to trigger which air chamber is filled
- Minimum moving parts (less wear)
- Tight tolerances to eliminate lost air
